Model
|
DSO3104A
|
|
Vertical System
|
|
Analog Channels
|
4
|
|
Bandwidth
|
150MHz(-3dB)
|
|
Rise Time
|
2.3ns
|
|
Input Impedance
|
Resistance: 1MΩ; Capacitance: 25 pF
|
|
Input Sensitivity
|
10mV/div to 5V/div
|
|
Input Coupling
|
AC/DC/GND
|
|
Vertical Resolution
|
8 bits
|
|
Memory Depth
|
256M/CH
|
|
Maximum Input
|
400V (DC+AC Peak)
|
|
Horizontal System
|
|
Real-Time Sampling Rate
|
1GSa/s
|
|
Time BaseRange
|
5ns/div to 1000s/div(1-2-5 sequences)
|
|
Time Base Precision
|
±50ppm
|
|
Trigger System
|
|
Source
|
CH1, CH2, CH3, CH4, EXT
|
|
Mode
|
Edge,Pulse,Viedo,Alternative
|
|
X-Y MODE
|
|
X-Axis Input
|
CH1
|
|
Y-Axis Input
|
CH2
|
|
Phrase Shift
|
Max.3 degree
|
|
Cursors and Measurement
|
|
Voltage Measurement
|
Vpp, Vamp, Vmax, Vmin, Vtop, Vmid, Vbase,Vavg, Vrms, Vcrms, Preshoot, Overshoot
|
|
Time Measurement
|
Frequency,Period, Rise Time, Fall Time, PositiveWidth, Negative Width, Duty Cycle
|
|
Cursors Measurement
|
Horizontal ,Vertical, Track, Auto Measure Modes
|
|
Waveform Signal Process
|
+,- , x,÷, FFT, Invert
|
|
AUTO SET
|
Yes
|
|
Voltage Range
|
10mV to 5V/div @ x 1 probe;
100mV to 50V/div @ x 10 probe;
1V to 500V/div @ x 100 probe;
10V to 5000V/div @ x 1000 probe;
100V to 50000V/div @ x 10000 probe;
200mV to 100V/div @ 20:1
|
|
Current Range
|
CC65(20A),CC65(60A),CC650,CC1100
|
|
FFT
|
Rectangular, Hanning,Hamming, Blackman Window
|
|
Math
|
Adition, subtraction, multiplication, division
|
|
Interface
|
USB 2.0
|
|
Power Source
|
8-36V wide range of input voltage, suitable for vehicle power test.
|
|
Volume
|
255 x 190 x 45 (mm)
|
|
Weight
|
1kg
|
